Sri DIGITEK® Three Phase Submersible & Borewell Controller
The Sri Digitek ULDX-DR-3PH is a specialized submersible pump controller and panel driver engineered specifically for 3-phase run motors[cite: 3]. Built with high reliability and low maintenance, this unique device maximizes motor lifespan across heavy-duty commercial and agricultural borewell applications[cite: 3].
⚙️ Key Features & Engineered Advantages
3-Phase Submersible Panel Driver
Designed as a unique device optimized for 3-phase run submersible motors to enhance operational longevity[cite: 3].
Advanced Low AC Voltage Sensing
Prevents electrode polarization in water using long-life stainless steel plastic molded conductive sensors that require zero frequent cleaning[cite: 3].
Comprehensive Visual Indications
Includes a 4-stage overhead tank level indicator, water flow indication, voltage level status, power ON, and auto/manual status indicators[cite: 3].
Dry-Run & Low Source Protection
Automatically shuts off the motor and signals a fault if running dry due to faulty foot valves, pipe air leaks, or low water sources[cite: 3].
3-Phase Voltage Cut-Off Range
Automatically cuts power if the supply voltage drops below 360V or crosses 500V AC across phases[cite: 3].
Soft Switches, NEED & Bypass Controls
Features Auto/Manual mode for utility tasks, an optional NEED switch to force-start regardless of water levels, and a Rocker Bypass Switch for failure overrides[cite: 3].
📋 Technical Specifications
| Model Code | ULDX-DR-3PH (Ultra Deluxe Series)[cite: 3] |
|---|---|
| Manufacturer | Smart Care Systems |
| Compatible Applications | Borewell pumps like Three Phase Submersible Pumps[cite: 3] |
| Working Voltage Cut-Off | Below 360V AC or Above 500V AC[cite: 3] |
| Sensor Technology | Stainless Steel Plastic Molded Conductive Electrodes (Low AC Sensing)[cite: 3] |
| System Build | MicroController Based Automatic Water Level Controller[cite: 3] |
| Operating Modes | Fully Automatic, Manual Mode, NEED Switch, and Rocker Bypass Switch[cite: 3] |
🏡 Ideal Applications
Three-Phase Submersible Pumps
Tailored explicitly for heavy-duty 3-phase industrial, agricultural, and large apartment borewell submersible motors[cite: 3].
Agricultural Borewells
Ensures rugged automation and voltage surge protection for high-capacity farm irrigation systems[cite: 3].
Commercial Complexes
Provides reliable unattended overhead distribution and low-source monitoring for large building infrastructures[cite: 3].
